cnc stone carving cutting machine

Share to:
    Min. Order: 1 Set/Sets

Basic Info

Model No.: 3012

Type: CNC Cutting Machine

Usage: Granite, Marble

Application: Art & Craft, Stone Industry

Source Voltage: 220V

Automation: Automatic

Cutting Ability: High Speed

Control: CNC

Certification: ISO, CE

Additional Info

Packaging: wood package

Productivity: 100 sets/month

Brand: Super star

Transportation: Ocean,Land,Air

Place of Origin: China

Supply Ability: 100 sets/month

Certificate: CE ISO SGS

Port: Qingdao Port

Product Description

18 tool holders Stone Engraving Machine

Feature:

1.ATC cnc stone processing center,which is an intergrated machine with the ability to cutting, edge grinding, dig a hole, block water after grinding,engraving. It is especially suitable for the processing of high-quality washbasin countertops and other shoped stones, ceramics, glass and microcrystalline stones,Fully automatic completion of the entire preset process.


2.the machine frame of heavy duty, especially, machine table is processed by 20mm aluminum, it will not out of shape after long time usage, also will not shake when working.
3.machine frame is milled by high precision five-surface milling center, get high precision and accuracy in machine.
4. assemble worker in factory has many years assembling experience in cnc router, can do perfect job, rack pinion can be installed in parallel by them, then can reduce abrasion, enhance precision. engineer has more than 20 years experience in stone industry. Can recommend you suitable engraving bits for different stone work. If there is some problem with Stone Cnc Router in future, engineer can gave fast solution in time, will not affect your production.
5.free training in our factory, will tell customer how to maximum Stone CNC Router function, enhance lifespan and reduce operation cost.


Stone Carving Marble Stone Machine is specialized in processing kitchen countertops. Stone Machinery For Sale all over the world. Machine Cutting Stone also called Headstone Cnc Machine.Especially,We have Stone engraving machine with four aixs that means the machine head can swing within 180 degree.so are you interested in the Stone cutting machine?


Parameters:

Model

3012

X Y working area

3000*1200mm

Z working area

800mm

Working table

20mm aluminum table with vacuum sucker(8 pieces)

Max work rate

2-10m/min

Drive motor

850W Yaskawa servo motor for x,y axis

1.3kw ysakawa servo motor for z axis

Control system

NK 300

Spindle

5.5Kw mechanical servo ATC spindle

Spindle Speed

24000rpm

Max process thickness

300mm

Reducer

Japan Shimpo Reducer

Tool changer

30 18 ATC tools,mainly are poloshing tools,used to polish countertop edge of stone,BT40

Voltage

380V/50hz

Engraving Command

G-code/HP-GL

Software operating environment

Windows2000/XP/98



Samples:




Looking for ideal Stone Machine for Marble Granite Quartz Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Heavy Duty ATC Granite Carving Machine are quality guaranteed. We are China Origin Factory of Carving Drilling Polishing Stone Cutting. If you have any question, please feel free to contact us.
