Wood door CNC Engraving Machine

Share to:
    Unit Price: USD 7000 - 9000 / Set/Sets
    Payment Type: L/C,T/T
    Incoterm: FOB
    Min. Order: 1 Set/Sets
    Delivery Time: 25 Days

Basic Info

Model No.: 1325

Certification: SGS, CE, ISO 9001

Usage: Woodworking

Current: AC

Power: High Power

Control: CNC

Drive Type: Stepper Drive

Condition: New

CNC Or Not: CNC

Place Of Origin: Shandong, China (Mainland)

Model Number: M1325

Additional Info

Packaging: Wooden box

Productivity: 100 sets/month

Brand: SUPERSTAR

Transportation: Ocean

Place of Origin: JINAN

Supply Ability: 100 sets/month

Certificate: CE SGS

Port: Qingdao

Product Description

Wood door CNC Engraving Machine



Single Head Woodworking Machine is a kind of Wood Cnc Machine, it has wide application as following:

Furniture: can process cabinet, wood door, solid wood, plate-type, windows, table, chairs, etc. made by Cnc Wood Milling Machine

Wood: Baffle box, Video Game machine cabinet, computer table, sewing machine table, musical instrument.

Decoration: screen, wave plate, huge-scale hanging, advertisement plates, markings making.


Except for this machine, we also have Wood Cnc Lathe Machine for your choice, its used for fast speed 3d wood carving. Also we have Multi Heads Woodworking Machine for 2d 3d carving.


Feature:

1. The imported straight-line party type guide rail,double row four row ball slide block,loading

capacity,smooth operation,high precision,long life.Import the ball screw high precision,lower knives

accurately.

2. The matching for choose NSK bearings imported from Japan's high-speed water-cooled motor.6 KW

air-cooled spindle 3.0 KW main spindle big power,stable performance.

3. On-line computer typed macro control system,adopting unique intelligent budget rules,give full play

to the motor potential and achieve high speed processing,song linear synchronous,curve more perfect.

4. Software compatibility and can be compatible type3 / Actcam /Castmate /Wentai and so no many

kinds of CAD/CAM design software.

5. Six partition vacuum adsorption mesa,can be effective in different size adsorption material.

6. By using high-speed drive stepping motor and drive,Y axis adopt double motor drive,make high-

speed operation of the 25 m/point above empty line speed,with strong cutting spindle can make the

sculpture speed more improved.

Product picture:

woodworking machinery



Product configuration:

X Working Area

1300mm

Y Working Area

2500mm

Z Working Area

200mm

Table size

1300x2500mm

Traveling Positioning Accuracy

±0.05mm

Repositioning Positioning Accuracy

±0.05mm

Table Surface

By suction

X,Y ,Z Structure

XY gear wheel, Z ball screw

Max. Power Consumption(Without spindle)

1840W

Max. Rapid Travel Rate

25000mm/min

Max. Working Speed

15000mm/min

Spindle Power Motor

3.0KW

Spindle Speed

0-24000r/min

Drive System

Stepper

Working voltage

AC220V/50Hz

Command

G-code

Packing and shipping:

woodworking machine parts



After-sale service:
woodworking machine planer
woodworking machine planner

woodworking machine in taiwan

multi function woodworking machine


Looking for ideal Multifunction Woodworking Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Woodworking Cnc Router Machine are quality guaranteed. We are China Origin Factory of Cnc Machine Woodworking Router. If you have any question, please feel free to contact us.
