JINAN HT MACHINERY CO.,LTD

CO2 Laser Cutter Machine 6090 80w 100w 130w
CO2 Laser Cutter Machine 6090 80w 100w 130w
CO2 Laser Cutter Machine 6090 80w 100w 130w
CO2 Laser Cutter Machine 6090 80w 100w 130w
CO2 Laser Cutter Machine 6090 80w 100w 130w

CO2 Laser Cutter Machine 6090 80w 100w 130w

Payment Type: L/C,T/T,Paypal,Money Gram,Western Union
Incoterm: FOB,CFR,CIF,EXW,CPT
Delivery Time: 3 Days

Add to Basket

Basic Info

    Model No.: CX6090

    Application: Leather Industry, Domestic, Carpentry, Printing & Packaging, Construction Industry, Molds & Dies, Crafts Industr, Advertising Industry

    Cooling System: Water Cooling

    Technical Class: Continuous Wave Laser

    Automatic Grade: Automatic

    Applicable Material: Nonmetal

    Type: Oscillating Mirror

    Laser Classification: Gaseous Laser

    Engraving Method: Vector Engraving

    Working Size: 600mm*900mm

    Working Table: : Honeycomb Or Knife Table

    Laser Type: : CO2 Laser

    Cutting Speed: : 1-1000mm/Min

    Control System: : DSP

    Min Line Width::  0.15-0.3mm

    Engraving Speed: : 1-6000mm/Min

    Location Precis::  0.015mm

    CNC Or Not: : CNC

Additional Info

    Packaging: Export plywood case

    Productivity: 2000 sets

    Brand: SuperStar

    Transportation: Ocean,Land,Air

    Place of Origin: Jinan,China

    Supply Ability: 500 sets per month

    Certificate: CE,ISO,SGS,FDA

    HS Code: 8456110090

    Port: QIngdao,Tianjin,Shanghai

Product Description

CO2 Laser Cutter Machine 6090 80w 100w 130w



Features of Nonmetal Laser Cutting Machine

The CO2 Laser Cutting Machine for Paper Wood Leather Acrylic

1.Adopting advanced DSP digital control system and intenational standard laser power supply, in integrated framework style, that make the working in high stability and high speed.

2.Transmitting files directly from Coredraw, AutoCAD, usb2.0 interface output can support off-line working.

3.The optimized and decent new design ensure the processing speed up to 1200mm/s with low price.

4.Big power and high stability laser, equiping with imported lens and mirror ensure the machines in a long life-span, one step cutting can reach 25mm thickness on acrylic.

5.Imported linear rail and high quality belt for transmission, equiping speed-down structure, ensure the product in high quality and stability cutting.

6.Automatic up and down table, rotary device, red dot position and vacuum system etc.


Specification


Model

CX6090

Processing area

600mm*900mm

Laser power

80/100/130/150/180W

Laser type:

Sealed Co2 laser tube

Resetting positioning accuracy:

±0.01mm

Compatible Software:

Laser cut 5.3, CorelDraw, AutoCAD, Photoshop

Whole machine size:

1420mm*1020mm*1150mm

Engraving speed

1-6000mm/min

Cutting speed

1-1000mm/min

Cutting thickness

0-20 mm acrylic (others determined by materials)

Resolution ratio

≤0.0125mm

Position system:

Red dot

Interface:

USB

Minimum shaping character

letter 0.8mm, Chinese 2mm

Support graphic format

DST, PLT, BMP, DXF

Gross power

1000W

Driving mode:

DC0.8A 24V stepper motor

Cooling mode:

Circulation water cooling

Working voltage:

AC 110 - 220V±10%, 50 - 60Hz or depend on customer

Operating temperature

0-45C

Operating humidity:

5-95%

Driving system

stepper

Option:

Up and down table, rotary attachment

Packing:

wooden box

Guarantee time:

2 years, laser tube 10 months

Option:

Rotary attachment for column materials

Operation:

Video to tell customer how to operate the machine

Net weight:

190KGS

Gross weight:

240KGS



Application to material of Nonmetal Laser Marking Machine:

Acrylic, wood, leather, bamboo, crystal, rubber, plastic, double plate, PCB board, glass, etc.

Laser Machine

Laser Engraving Machine

Samples

1538260747724222671

5


Certificate:

CE cerficificate for European countries
CCVO SONCAP cerficiate for Nigeria customers
FTA certificate for Pakistan customers
SASO certificate for Saudi Arabic customers

Form E certificate for Indonesia and Vietname customers.

Reputation


Package and Delivery
1. Packed by standard plywood case, it has strong bearing strength.

2. When importing, the plywood case is with fumigation-free, the procedure is simple.

3. Delivery Detail: within 7-15 days after received your payment.



Our service
18 months guarantee of the whole machine, we will provide the consumable parts at an agency price when you need replacement.

Main parts(excluding the consumables) shall be changed free of charge if there is any problem during the warranty period.

Software is on update for free whole life.
Our engineer could support you technology to your country if necessary.
We could train you in our factory for free, also could service you 24 hours online by Skype, whatsapp or by cellphone.
English manual and CD video for machine using and maintaining will send to you with the machine.


Company introduction


Jinan Jinshengxing Machinery Manufacture Co., Ltd. was founded in 2003, dedicated to manufacture woodworking

machine, such as 3d cnc router, multi heads cnc router, automatic tool changer cnc router, cnc router with CCD and

Oscillating knife cutting head. etc.

Own 70000 square meters factory, 3 production base

300 workers

50 overseas servicing engineer

has 10 overseas warhouse in pakistan, uzbekistan, vietnam, south africa, kazakstan, kenya, myanmar, thailand,

turkey and russia. Customers from these countries can take stock machine immediately after pay case, and local

servicing person will help you install machine and provide training.

CE cerficificate for European countries

CCVO SONCAP cerficiate for Nigeria customers

FTA certificate for Pakistan customers

SASO certificate for Saudi Arabic customers

Form E certificate for Indonesia and Vietname customers

Nonmetal Laser Machine

3D Laser Engraving Machine


1


Welcome visit our factory !

name card

Looking for ideal Co2 Laser Cutting Shoes Design 6090 Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Co2 Laser for Non-metal are quality guaranteed. We are China Origin Factory of Laser Applicable Acrylic MDF Fabric. If you have any question, please feel free to contact us.
