Home > Products > Laser Marking Machine > Fiber Laser Marking Machine > chinese fiber laser marking machine 30w

chinese fiber laser marking machine 30w

Share to:
    Payment Type: L/C,T/T,Paypal
    Incoterm: FOB,CFR,CIF
    Min. Order: 1 Set/Sets
    Delivery Time: 5 Days

Basic Info

Model No.: CX20

Laser Visibility: Visible

Applicable Material: Metal

Cooling System: Air Cooling

Technical Class: Pulse Laser

Laser Wavelength: Fiber Laser

Laser Classification: Solid Laser

Type: Optical Fiber Laser Marking Machine

Marking Method: Scanning Marking

Laser Power: 10W 20W 30W 50W 100W

Laser Source: Raycus Brand

Working Size: 100*100mm, 150*150mmmm

Control System: Beijing JCZ

Software: EZCAD

Warranty: 1 Year

Machine Table: 2d Working Table

Up-down Function: Include

Red Dot: Dual Red Dot

Lens: USA Brand

Additional Info

Packaging: fumigation-free plywood case

Productivity: 100sets/month

Brand: super star

Transportation: Ocean,Land,Air

Place of Origin: china

Supply Ability: 100set/month

Certificate: iso, ce

HS Code: 8456110090

Port: Qingdao,Shanghai,Tianjin

Product Description

Fiber Laser Marking Machine 30w




1 20W fiber laser engraver machine

2 Applicable materials:Applicable various metal,.alloy and some non-metal materials.

3 Applicable industry:

Metal,alloy ,oxide,ABS,epoxy resin,printing ink,etc. which are widely applying for electronics,jewelry,automobiles,communication products,plastic buttons,IC,etc.


10w 20w 30w 50w fiber Laser Marking Machine technical parameter

Model

CX20

Laser power

10W/20W/30W50W

Supports graphical format

PLT, BMP, JPG, PNG, TIP, PCX, TGA, ICO, DXF

Beam quality

m2 <2

Power stability

(8h) <± 1% rms

Pulse repetition frequency

20KHZ ---- 100KHZ

Power consumed

<800W

Minimum line width

50μm

Minimum character

0.3mm

Laser Wavelength

1064nm

Galvanometer Size

110 * 110mm (optional)

Whole machine power

500w

Cooling way

Air cooling

Operating voltage

110/220V ± 10% /,50/60HZ

Ambient operating temperature

15 ° C - 35 ° C

Weight

80KG

Dimensions

600H * 200W * 700L (mm)

Packing

plywood wooden packaging





























fiber laser engraver machine is Optical Fiber Machine, also called fiber laser marking machine, its mainly used to mark on metal, alloy, stainless steel, aluminium etc. and few nonmetal such as hard plastic, rotary can be added engrave on bottles, rings etc. it can be 50w fiber laser engraver machine and 20w Fiber Laser Marking Machine. WE have Portable Fiber Laser Marking Machine Desktop Fiber Laser Marking Machine, all machine is equiped with computer, welcome to your inquiry



Our Services:

1.One year quality guaranty, the machine with main parts(excluding the consumables), shall be changed free of charge when if any problem during the warranty period.

2.Lifetime maintenance free of charge.
3.Free training course at our plant.
4.24 hours on line service each day, free technical support.
5.Machine has been adjusted before delivery

Samples:


laser marking

Workshop:

laser marking machine

Factory:


Own 70000 square meters factory, 3 production base
300 workers
50 overseas servicing engineer
has 10 overseas warhouse in pakistan, uzbekistan, vietnam, south africa, kazakstan, kenya, myanmar, thailand, turkey and russia. Customers from these countries can take stock machine immediately after pay case, and local servicing person will help you install machine and provide training.
CE cerficificate for European countries
CCVO SONCAP cerficiate for Nigeria customers
FTA certificate for Pakistan customers
SASO certificate for Saudi Arabic customers

Form E certificate for Indonesia and Vietname customers.

1


50w fiber laser engraving machine


fiber laser marking machine30w fiber laser engraver

Looking for ideal Fiber Laser Marking Machine 50w Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Fiber Laser Engraving Machine 50w are quality guaranteed. We are China Origin Factory of Chinese Fiber Laser Marking Machine. If you have any question, please feel free to contact us.
