JINAN HT MACHINERY CO.,LTD

steel sheet metal laser cutting machine price
steel sheet metal laser cutting machine price
steel sheet metal laser cutting machine price
steel sheet metal laser cutting machine price
steel sheet metal laser cutting machine price

steel sheet metal laser cutting machine price

Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF
Min. Order: 1 Set/Sets
Delivery Time: 45 Days

Add to Basket

Basic Info

    Model No.: FB3015

    Laser Power: 500w, 1000w 1500w

    Fiber Laser Source: Raycus And IPG

    Control System: Au3tech, Cypcut

    Transmission: Helical Rack Pinion

    Machine Table: Gear Table

    Driving: Japan Yaskawa Servo

    Cooling Equipment: Water Chiller

    Auxiliary: Exhaust Fan, Dust Removing Device

    Working Size: 1300*2500mm, 1500*3000mm

    Optional: Rotary Attachment, Full Housing And Exchange Table

    Application: Automotive Industry

    Cooling System: Water Cooling

    Technical Class: Continuous Wave Laser

    Applicable Material: Metal

    Structure Type: Gantry Type

    Laser Classification: Free Electron Laser

    Laser Technology: Laser Flame Cutting

Additional Info

    Packaging: fumigation-free plywood case

    Productivity: 100sets/month

    Brand: super star

    Transportation: Ocean

    Place of Origin: china

    Supply Ability: 100set/month

    Certificate: iso, ce

    HS Code: 8456110090

    Port: Qingdao,Shanghai,Tianjin

Product Description

steel sheet metal Laser Cutting Machine price

1

Advantage of Fiber laser

1, High electro-optical conversion efficiency, 300% more efficient than CO2 laser

2, Low operating and maintenance cost, only 6% of CO2 laser

3, High cutting speed, 600%~1000% faster than CO2 laser

4, Small in size, light in weight, mobile working position, minimum space requirement


Fiber Laser Cutting Machine can also be called CNC Fiber Laser Cutting Machine, belongs to Laser Fiber Cutting Machine, super star Fiber Laser Cutting Machine 500w can be made into fiber pipe laser cutting machine, is applicable for furniture, medical device, fitness equipment, oil exploration, display shelf, farm machinery, bridge, boating, structure parts industry, etc. pipe cutting 1000w Fiber Laser Cutting Machine, is specially for round, square, rectangular, oval, waist round tube and other metal pipes.


Cutting thickness is 0.5-22mm. (length of pipes is 6m, diameter of pipes is 20mm-200mm), welcome to contact us for Fiber Laser Cutting Machine Price


2

Technical Parameter:


Model

FB1325-300

Working Area (X*Y)

1300mm*2500

Table type

Knive table

Laser wavelength

1080nm

Power and cutting head

300W Raycus Leetro MPC6595 controller

Laser power injection

1.6 KW

Water chiller power

6000

X-axis and Y-axis Location accuracy

±0.05mm

X-axis and Y-axis repeat location accuracy

±0.01mm

Max moving speed

30m/min

Max. cutting speed

20m/min

Min. cutting line width

0.02mm

Applicable material

Stainless steel, carbon steel, aluminum, copper, titanium plate, iron ,etc.

Cutting thickness

Stainless steel 2mm, carbon steel 3mm

Whole machine floor space

3.5×2.2×1.5m


3

WHY Choose super star Fiber Laser Metal Cutting Machine

Stable Z-axis and auto focus system

The laser head equipped with Au3Tech adjustor, Able to adjust focal length automatically, guaranty the best cutting quality, prevent material scrapping caused by changing of focal length when metal is not flat Due to non-contact sensing device, when controlled by system, able to achieve stable Z axis floating function, eliminate negative effects caused by non-flat material


Machine shell / Host machine:

large scale cutting machine weight 3.7 tons. We take producing cost, machine stability and machine quality all into consideration. After seral times redesign we decide the final simple but strong design. Which produced by professional large scale equipments from military level industry, and passed aging treatment, can guaranty durability for long term use.


Transmission

Machine equipped famous brand high precision ball-screw system, linear guide and motor servo drive system, can guaranty the processing precision. The transmission system can match the CNC control system smoothly.


Control system

Use professional IPC, optimization cutting calculate system, touch screen easy to use, professional cutting software can design all kinds of graphic, text, support CAD, CorelDraw.

4

Applicable materials and industry

Suitable for stainless steel, carbon steel and some other metal materials precise cutting, applicable for aerospace technology, rocket, plane, robot,elevator, steamship and automobile manufacturing and metal parts processing industry for metal plate, advertisement, kitchen ware, bit tool, hardware etc


56




Looking for ideal Cnc Laser Cutter Steel Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Small Laser Metal Cutting Machine are quality guaranteed. We are China Origin Factory of Laser Metal Cutting Machine Price India. If you have any question, please feel free to contact us.

Product Categories : Laser Machine > Fiber Laser Cutting Machine
