ATC cnc router woodworking Machine

Share to:
    Unit Price: USD 14500 - 22000 / Set/Sets
    Payment Type: L/C,T/T
    Incoterm: FOB
    Min. Order: 1 Set/Sets
    Delivery Time: 25 Days

Basic Info

Model No.: CX-M25

Type: Wood Router

Controlling Mode: CNC

Feed Mode: Mechanical

Spindle Layout: Vertical

Certification: SGS, ISO, CE, CE&ISO

Screw: Multi-Screw

Spindle Number: Double-Spindle

Precision: High Precision

Plastic Processed: PVC

Cutting Machine Type: CNC Cutting Machine

Condition: New

CNC Or Not: CNC

Place Of Origin: China (Mainland)

Brand Name: Superstar

Model Number: SKM25

Voltage: 380V/50HZ/3PH

Dimension(L*W*H): 320*210*185cm

Weight: 1500kg

Warranty: One Year

Additional Info

Packaging: wooden package

Productivity: 100/month

Brand: SUPER STAR

Transportation: Ocean

Place of Origin: JINAN

Supply Ability: 100/month

Certificate: ISO CE

Port: Qingdao

Product Description

9kw HSD Italy air cooled spindle ATC Woodworking Machine/Auto Tool Changer Woodworking Machine


The CNC Router 1325 ATC with carousel Tool Magazine loaded with the spindle can change the tool automatically tool capacity is 8,tool change time is 8 seconds.

♦ 1325-ATC is used for 2D&3D engraving and cutting,carving .


Application of Cutting Wood Machine:

Furniture Industry: wood doors, cabinets, tables,chairs

Advertising Industry:signage,logo,badges,display board,meeting sign board,billboard

Artwork and Decoration Industry:wood crafts, gift box, jewelry box

Electronic Industry:circuit board, insulation material

Music Industry: musical instrments, loudspeaker box

Soft Metal: aluminum, brass


Product configuration of Engraving Cnc Machine:


Number

Description

Parameter

1

X,Y,Z Working Area

1300mmx2500mmx200mm

2

Table Size

1330mm×3040mm

3

X,Y,Z Traveling Positioning Accuracy

±0.03/300

4

X,Y,Z Repositioning Accuracy

±0.03mm

5

Table Surface

Vacuum and T-slot Combined (Option: T-slot table)

6

Frame

Welded structure

7

X, Y Structure

Rack and Pinion Drive, Hiwin Rail Linear Bearings

8

Z Structure

Hiwin Rail Linear Bearings and Ball Screw

9

Max. Power Consumption

4.5kw (Without Spindle)

10

Max. Rapid Travel Rate

45000mm/min

11

Max. Working Speed

30000mm/min

12

Spindle Power

9.0 kw

13

Spindle Speed

0-24000RPM

14

Drive Motors

Yaskawa servo motor

15

Working Voltage

AC 380V/50/60Hz,3PH

16

Command Language

G Code

17

Operating System

Syntec Control System

18

Computer Interface

Ethernet, CF Card

19

Flash Memory

128M(U Disk)

20

Collet

ER32

21

X,Y Resolution

<0.03mm

22

Software Compatibility

Type3/UcancameV9 software (Option: Artcam software)

23

Running Environment Temperature

0 - 45 Centigrade

24

Relative Humidity

30% - 75%

25

Packing Size

3300X2100X1980mm

26

N.W.

1450KG

27

G.W.

1670KG

28

Optional Parts

3.8KW HSD Auto Spindle

Syntech Control System

Dust Collector

Vacuum Pump

Rotary System

Mist-cooling System

850W Yaskawa/800W Panasonic Servo motors


Product picture of 3D Cnc Machine:


cnc wood cutting machine


wood tech cnc machine


Packing delivery of Cnc Wood Milling Machine:

wood sculpture machine

Our service team for Wood Sculpture Machine:

 cnc router 1325cnc router woodwork cc-m1325a


cnc wood door engraving machine

wood cnc machine germany

china wood carving machine



Looking for ideal Cnc Wood Door Engraving Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the 1325 Wood Cnc Router are quality guaranteed. We are China Origin Factory of Wood Cnc Router 1325. If you have any question, please feel free to contact us.
