Home > Products > Advertising Machine > fiber laser metal cutting machine carbon steel

fiber laser metal cutting machine carbon steel

Share to:
    Payment Type: L/C,T/T,D/P,Money Gram,Western Union
    Incoterm: FOB,CIF,EXW
    Delivery Time: 7 Days

Basic Info

Model No.: CX1530 fiber laser cutting machine

Application: Advertising Industry

Cooling System: Water Cooling

Technical Class: Other

Applicable Material: Metal

Structure Type: Gantry Type

Laser Classification: Solid Laser

Laser Technology: Laser Flame Cutting

Additional Info

Packaging: export plywood packed

Transportation: Ocean

Port: Qingdao

Product Description

Machine Model

CX-1530 500w Fiber Laser Cutting Machine

Max. working area

1500*3000mm

Cutting thickness

0.2-3mm stainless steel / 0.2-6mm carbon steel

Laser wavelength

1064nm

Laser head

Shanghai Jiaqiang laser head(Au3Tech laser head optional)

Out put Power

500W Raycus fiber laser source (10-100%)

Water chiller power

CW6100 water chiller

Guide rail

Taiwan TBI 25mm Square rail

XY axis Motor

Japan Yaskawa servo motor

Reducer

Japan shimpo reducer

Oil system

Electric oil filling system

Guide rail

Taiwan TBI 25mm Square rail

Z axis Motor

Japan Yaskawa servo motor

Controller system

Cypcut controller (Au3Tech laser controller optional)

X,Y-axis fast moving speed

80m/min

X,Y-axis max. cutting speed

20m/min

Min. cutting line width

± 0.02mm

positioning accuracy

±0.05mm/m

Positioning speed

20m/min

Aiming positioning

Red light

Power consumption of the whole machine

12KW

Auxiliary cutting gas

Oxygen, nitrogen and air

Machine weight

2500KG

Whole machine floor space

4800x2600x1800mm


Advantage of Fiber laser:
1,High electro-optical conversion efficiency, Fiber Laser Cutting Machine Price 300% more efficient than CO2 laser laser ebgraveing machine for metal

2, Low operating and maintenance cost, only 6% of CO2 laser Laser Metal Engraving Machine

3, High cutting speed, Fiber Laser Cutting Machine 600%~1000% faster than CO2 laser
4, Fiber laser cutting machine price Small in size, light in weight, mobile working position, minimum space requirement

WHY CX-LASER:
Fiber Laser Cutting Machine Price Stable Z-axis and auto focus system
The laser head equipped with Laser-Mech(Made in U.S.A) capacitor non-contact AUTO-FOCUSING system,
Able to adjust focal length automatically, guaranty the best cutting quality, prevent material scrapping caused by changing of focal length when metal is not flat
Due to non-contact sensing device, when controlled by system, able to achieve stable Z axis floating function, eliminate negative effects caused by non-flat material
Machine shell / Host machine
CX-LASER large scale cutting machine weight 3.7 tons. We take producing cost, machine stability and machine quality all into consideration. After several times redesign we decide the final simple but strong design. Which produced by professional large scale equipment from military level industry, and passed aging treatment, can guaranty durability for long term use.
Transmission
Machine equipped famous brand high precision ball-screw system, linear guide and motor servo drive system, can guaranty the processing precision. The transmission system can match the CNC control system smoothly.
Control system
Use professional IPC, optimization cutting calculate system, touch screen easy to use, professional cutting software can design all kinds of graphic, text, support CAD, CorelDraw.

Certifiacte:
Fa213378e729be94a1c6272bed8329e



Looking for ideal Steel Cutting Laser Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Carbon Fiber Laser Machine are quality guaranteed. We are China Origin Factory of Cnc Metal Laser Cutting Machine. If you have any question, please feel free to contact us.

Product Categories : Advertising Machine
